State-of-the-art facilities for precision machining
Want precision machining you can count on?
Then work with a supplier who gets its own facility right down to the last detail.
Because if your partner is willing to settle for less than the best with its own shop, it won’t optimize your part either.
The high-quality you want, when you want it, the way you want it.
Tour Avoda's Facilities
Welding Department
Welding is our specialty. Whether you need large-volume runs or complex one-off jobs, we’ve got you covered.
- Complete in-house weldments from start to finish
- Custom fixtures from our own CNC machining department
- Weldments up to 6’x6’x24’—larger capacity available upon request
- AWS certified
Laser Cutting Machine 1
Thanks to our 15KW fiber laser with integrated automated tower system, we offer a precision, scalable laser-cutting service. We specialize in projects that demand a fast turnaround.
- 4020 table cutting size
- Dynamic speed function with accessories
- Fully automated sorting of cut parts
- Diverse materials
- Aluminum up to 1.125”
- Stainless steel up to 1.125”
- Mild steel up to 1.5”
- Brass up to 0.375”
- Copper up to 0.375”
Tube Laser Cutting Machine 2
With a high-speed tube laser 7000 Series Trumpf Machine, we can increase tube speeds while minimizing costs.
- Bevel cutting head for complex geometries, shapes, and bevels
- XXL chuck for tubes up to 10” diameter
- 30’ feed with automated loading
- 24’ out-feed with automated unloading
- Cuts tubes up 0.5” thick
- Diverse tube shape
- Round
- Rectangulae
- Square
- Angled
Bending & Forming Machine 3
With best-in-class offline programming, our bending & forming service gets you the part you want without sacrificing speed.
- 350 tons of brake press capacity
- 14’ long die bed
- Independent 6-axis back gauge system
- High-speed light curtains
Saw Cutting Department
Our 60-degree miter saw offers:
- 20”x 25” capacity
- Auto-bar feeding with 156” index
- 53” in-feed and out-feed lengths
Round material
- At 0°: Diameter 20.00” (508mm)
- At 45°: Diameter 17.00” (432mm)
- At 60°: Diameter 11.25” (286mm)
Rectangular Material
- At 0°: 20.00” x 25.00” (508mm x 635mm)
- At 45°: 20.00” x 17.00” (508mm x 432mm)
- At 60°: 20.00” x 11.25” (508mm x 286mm)
CNC Machining Department
With CNC mills and lathes, we offer all the machining capabilities required to produce complex high-tolerance parts and incorporate them into turnkey weldments.
CNC Lathe
- Automated bar feed up to 3” diameter
- Live tooling
- Complex geometries
- Sub-spindle for automation
- Y-axis milling, drilling, and tapping
CNC Milling
- Travels up to 64” x 32” x 30”
- Automated tool changers
